Eclipse 56' Triple Expando IP/UHD/HDR MPU

• Studer Vista X 600, Fully Redundant, W/ 72 Faders on the Surface and 2 x Lexicon PCM96 "Plug-In" Efx
• 4- 48X16 Studer Stage Boxes Connected via SMPTE or TAC Fiber
• 64 Channels of DANTE I/O x 2, Multiple MADI Streams, Analogue, and AES I/O
• Telos Phone Interfaces
• 4 Engine TC Electronics System 6000
• 8 Channels Cedar Noise Suppression
• Extensive MADI Routing and Access
• Extensive DANTE Routing and Access
• 5.1 Audio Monitoring/ 'JBL 7' Speakers
• All Positions – Multi-Channel Routable Audio Monitors

• 16 Grass Valley LDX 150 IP Native Cameras (Wired for up to 18) W/ Creative Grading

• Wired for 2 CG Machines in HD or UHD

No information available.

No information available.

• 4-BVM-HX310 TFT LCD HDR/4K Monitors in Production
• Monitor Wall Includes 6-49" and 2-75" Monitors Displaying Grass Valley Multiviewer
• 3-Sony BVM-HX310 TFT LCD in Video Position
• 1-Sony BVM-HX310 TFT LCD in LD Position
• 56- XiP Up/Down/Cross Converters
• Split Position in Control Room Allowing 2 Extra Seats W/ Intercom and Multiviewer
• Divider Available If Needed to Separate From Control Room
• Dante, Gpi, 422, Phones, Truck Networks Available in the Field
• A-Unit: (All Measurements Without Tractor) 55'8" Long x 13'6" High x 8'6" Wide– Closed (W/ the Longest Tractor Length is 77'4") 65'11" Long x 13'6" High x 15'6" Wide– Expanded W/ AC Flaps Open & Stairs Parallel to Truck (Add 5 ft to Width if Stairs Perpendicular to Curb)
• B-Unit: (All Measurements Without Tractor) 50'4" Long x 13'6" High x 8'6" Wide– Closed
• A-Unit: One service of 400 AMP 3 Phase 208 Volts (if 4/o feeder cable is supplied by a 3rd party), or Two services of 200 AMP 3 Phase 208 Volts each (Eclipse carries 2/o feeder cable for 2×200 AMP services)
• B-Unit: One service of 100 AMP 3 Phase 208 Volts (Only Required if Used for Production)

• Up to 4 12-Channel EVS
• 80 Record Channel Capable in HD
• 40 Record Channels in UHD

• GV Orbit Monitoring Control System with Cisco Fabric, Spine and Leave Architecture; 1200 Source X 2400 Destinations Router 2022-7 Redundancy Supporting HD, 3G, UHD, 4K
• 32 IN and 32 OUT Single Mode ST Fiber to I/O

• Grass Valley 6 M/E K Frame XP/IP (UHD/3G/HD Capable) Switcher 6 ME W/ 6 Keyers per M/E
